STORM SIGNALS
Summer 1999, Vol. 52


[Storm Signals Main Page] - [NWSO Houston/Galveston] - [Comments]


CONTENTS



This edition of Storm Signals was printed by the Harris County Office of Emergency Management.
James F. White, Coordinator
Frank E. Gutierrez, Operations Coordinator
Laverne Thompson, Deputy Coordinator




Locating Weather & Climate Records
All weather and climate data gathered by the National Weather Service, military services, Federal Aviation Administration, and Coast Guard is kept at the National Climatic Data Center in Asheville, North Carolina. The NCDC compiles the weather data (temperatures, precipitation totals, heating and cooling degree days, and more) collected from thousands of sites in the U.S. Records kept by local National Weather Service offices are forwarded to the NCDC on a regular basis, but you can expect a lag of 2-4 weeks before today's data is on file at the NCDC.



What a Difference a Year Makes!
By Charles Roeseler

Weather patterns change from year to year. Some years, the change is imperceptible, while other years the change can be striking. The latter was the case this year. The months of May and June 1998 were very hot and dry while May and June 1999 were warm and wet. A comparison of May and June temperature and precipitation data will be provided for College Station, Galveston and Houston's Intercontinental Airport for the years 1998 and 1999. The differences between the two years are rather dramatic.

College Station Data

  May 1998 May 1999
Average High/Low/Daily 91.2/67.50/79.4 85.3/64.50/74.9
Rainfall (inches) 0.11 4.16



  June 1998 June 1999
Average High/Low/Daily 98.0/75.30/86.7 90.3/72.65/81.5
Rainfall (inches) Trace 4.61

Galveston Data

  May 1998 May 1999
Average High/Low/Daily 82.7/72.9/77.8 82.7/72.3/77.5
Rainfall (inches) 0.02 3.56



  June 1998 June 1999
Average High/Low/Daily 88.3/79.2/83.8 87.7/78.1/82.9
Rainfall (inches) 9.43 2.35

Houston Intercontinental Data

  May 1998 May 1999
Average High/Low/Daily 90.3/67.0/78.8 87.4/65.8/76.6
Rainfall (inches) 0.04 4.13



  June 1998 June 1999
Average High/Low/Daily 95.1/75.9/85.5 90.5/73.2/81.9
Rainfall (inches) 2.87 5.26

(Note: Above statistics are compiled through June 30, 1999.)

The College Station average daily temperature was 4.5 degrees warmer in May 1998 than May 1999. June of 1998 was a sweltering 5.2 degrees warmer than June 1999. All four months examined had average daily temperatures above normal. What is really striking is the number of 90 and 100 degree days observed in 1998. College Station reached or exceeded 100 degrees 12 times in May and June of 1998. That plateau has not been reached so far this year. In 1998, the temperature reached or exceeded 90 degrees 47 times in the two month period. So far this year, the temperature has reached or exceeded 90 degrees 25 times. 13 temperature records were tied or broken during the two month period in 1998 while this year there has only been one temperature record set. So far this year, the highest temperature recorded at Easterwood Field was 94 degrees which occurred on June 6th. In 1998, 94 degrees was reached on May 7th and was reached or exceeded another 11 times before June 6th. Clouds and rainfall typically suppress warmer temperatures and that was certainly the case this year. The two month rainfall total (1998) for College Station was 0.11 inches while in 1999 the rainfall was 8.83 inches.

Similar trends were observed at Houston. The average daily temperature was 2.1 degrees warmer in May 1998 than May 1999. In June, the difference was 3.6 degrees. There were 44 days last year which reached or exceeded 90 degrees during May and June. This year, 90 degrees has been reached or exceeded 32 times. 100 degree temperatures have not been reached this year, but in 1998 the century mark was reached twice. Clouds and rain helped keep temperatures cooler than last year but still above climatological normals. In 1998, rainfall in May and June totaled 2.91 inches while in the 1999, the two month rainfall was 9.39 inches.

Galveston, a coastal site, has a climate greatly influenced by the gulf. Temperatures typically don't vary much from year to year. However, rainfall totals can vary dramatically. Despite, the strong drought much of Texas endured last year, Galveston received 9.45 inches of rain in May and June (1998). Much of the rain which fell in that period occurred on June 27th and 28th when a weak coastal trough of low pressure developed. Areas from Palacios to High Island received six to eight inches of rain from that system. Skies remained dry 50 miles or more inland. This year (non-drought), Galveston received 5.91 inches of rain. Rain fell on eight days during the two months in 1998. In 1999, rain occurred on 22 days. So despite the lack of rainfall parity between the two years, the 1999 rainfall totals were more beneficial to agricultural interests. Temperature differences between the two years was less than a degree but all four months had temperatures which averaged above climatological normals.

A quick look at long range climate projections indicate that much of eastern Texas can expect rainfall to remain near normal levels while temperatures climb a degree or two above climatological normals. High temperatures in July and August are typically in the mid and upper 90s and average rainfall is 3 to 4 inches per month. These projections will be altered quickly if a tropical system should make a visit to southeast Texas later this summer.

The following is a list of rainfall data for many supplemental sites across southeast Texas.



SITE MAY 1998 JUNE 1998 MAY 1999 JUNE 1999
Anahuac 0.00 3.96 6.37 5.83
Angleton 0.00 2.12 5.17 4.62
Bay City 0.00 0.83 6.99 6.29
Brenham 0.09 3.94 5.23 5.70
Caldwell 0.31 0.00 4.32 3.29
Cleveland 0.02 2.55 5.77 4.27
College Station 0.11 Trace 4.16 4.61
Col. River Locks 0.50 8.40 2.87 4.07
Columbus NA 1.33 4.75 7.02
Corrigan 0.03 2.56 7.04 7.96
Crockett 0.00 0.30 5.07 4.23
Dacus Trace 1.24 4.71 4.01
Danevang 0.05 0.29 4.16 6.21
Deer Park 0.00 3.41 8.48 7.36
Edna NA 0.24 4.61 6.50
El Campo 0.02 0.95 5.41 6.10
Galveston 0.02 9.43 3.56 2.35
Groveton 0.14 0.67 6.77 9.40
Houston Heights 0.00 3.50 6.90 10.33
Houston Hobby NA NA 6.41 6.77
Houston IAH 0.04 2.87 4.13 5.26
Huntsville 0.04 1.03 5.45 4.90
Livingston 0.23 0.99 4.53 8.07
Madisonville 0.11 0.30 1.54 5.31
Midway 0.53 0.84 4.17 4.86
Montgomery 0.01 2.26 4.86 6.11
NWSO HGX Trace 4.84 2.35 11.57
Pearland 0.00 1.15 5.00 12.33
Pierce NA 1.01 3.53 5.30
Richmond 0.50 1.95 4.43 6.28
Sealy 0.09 0.52 5.33 4.17
Sugarland 0.08 1.80 6.87 7.04
Texas City 0.00 9.19 3.52 4.75
West Columbia 0.00 2.15 3.63 3.28

BACK UP TO CONTENTS TABLE



1999 Hurricane Season .... Quiet So Far
By Josh Lichter

So far this hurricane season, through July 28th, there has been only one Atlantic basin tropical cyclone. Arlene originated in the subtropical Atlantic about 550 miles southeast of the island of Bermuda from a non-tropical disturbance...along the remains of a front...on June 11th. The disturbance strengthened and became a tropical storm the following day while drifting northward. Arlene threatened Bermuda with peak winds at 50 mph but passed about 100 miles to the east and did not significantly impact the islands. Arlene dissipated on the 18th to the northeast of Bermuda.

Both the National Oceanic and Atmospheric Administration's (NOAA) Climate Prediction Center (CPC) and Dr. William Gray, professor at Colorado State University, continue to forecast an active 1999 hurricane season. On their June 16th forecast, the CPC said that most of the activity is expected to occur during the peak three months (August-October) of the season. On June 4th, Dr. Gray and his colleagues predicted that low latitude formations will dominate which will lead to a more active Caribbean and Gulf of Mexico basin. Dr. Gray is calling for fourteen named storms, nine of which become hurricanes. Four of the hurricanes are expected to reach intense status, which is category 3, 4, or 5 on the Saffir-Simpson hurricane scale.

So far this season, systems that have come off the west coast of Africa have raced westward toward the Caribbean Sea and have not developed. The season is still young, and residents across Southeast Texas are still urged to closely monitor the tropics. Texas has not been struck by a hurricane since 1989, and the last major hurricane strike was from Alicia in 1983.

Our office still gives hurricane preparedness talks to schools, businesses, and organizations that may be beneficial to you and your employees. If you are interested in one of these presentations, please contact our office at (281.337.5074) or by email at joshua.lichter@noaa.gov.

BACK UP TO CONTENTS TABLE


Hurricane Issues
By Bill Read

The extremely active hurricane seasons since 1995 and data collected from them have provided researchers on hurricane preparedness insight on a number of key issues facing the United States. These issues and how we deal with them are of significant importance to citizens living along the Texas Coast. Jerry Jarrel, Director of the National Hurricane Center, presented these issues at the EHCMA sponsored Houston/Galveston Hurricane Workshop on May 7th. A short summary of the most important issues and how they relate to our area is presented below:

1. Length of time between major storms.
The return rate for category 3 or higher storms ranges from 10 to 15 years over south Florida to over 25 years on the Atlantic coast states. Texas return frequency is around 15 years. Our last category 3 storm was Alicia and our last category 4 storm was Carla. The last direct strike to the Houston/Galveston area by a category 4 storm was the 1915 hurricane. A significant percentage of the population has moved here since Alicia while the vast majority either weren't born yet or have moved here since Carla. One's perception of the potential for a hurricane is tied to their personal history with the event. With the continued rapid growth of population and industry in the hurricane zone, this confusion between perception and what actually can happen will continue to grow as an issue. The challenge for local officials and meteorologists is convincing people we are not overstating the threat from the "Big One."

2. Need for longer lead time.
The rapid growth in population is increasing the complexity of evacuation planning, decision making and execution. Some 250,000 people lived in the evacuation zones when Carla hit in 1961. Now we have 1.3 millionpeople. The corresponding growth in required evacuation time has and will likely continue to be equal to or greater than meteorologists' improvements in track and intensity prediction. As complex as preparation and evacuation has become for the Houston/Galveston areas, we are far from the worst. Some locations such as New Orleans and Miami would require more than 50 hours to evacuate for a category 4 or 5 storm. Locations in our area may need up to 36 hours.

3. Can a catastrophe like the 1900 storm still occur in the United States?
We look at the catastrophic loss of life due to Mitch in Central America and say that can't happen here. Lesson's learned from 1995's Hurricane Opal in the Florida Panhandle and last year's Hurricane Georges in the Florida Keys suggest otherwise. When the Hurricane Warning went up the day before Opal made landfall, relatively few people evacuated. The hurricane was supposed to arrive late the next day and was forecast to be a category 2. Overnight Opal intensified to a strong 4 and moved much faster than anticipated. People woke up the next morning facing a serious threat. What evacuation that occurred did not go well and most people ended up staying in the area. Fortunately, Opal weakened to a category 2 before striking land. The concern is that another storm in a different place will do an Opal but not weaken, trapping thousands of people in the surge zone, possibly in their cars trying to flee at the last minute. The Georges scenario or "Key West" problem occurred due to public lack of confidence in the viability of the evacuation routes. In the Florida Keys there is only one way out - a two lane highway. Although ordered to evacuate some 36 hours in advance, only half the citizens of the Florida Keys went. Had Georges strengthened to a category 3 or 4 hurricane, catastrophic loss of life may have occurred. Will the next such community facing a similar scenario be so fortunate?

4. Inland fresh water flooding.
Since Camille in 1969, significantly more people have drowned due to flooding from tropical storm and hurricane rainfall than from storm surge. Once again, growth of population in flood prone areas in the southern United States has increased the potential for damage and loss of life due to fresh water flooding.

5. Disaster resistant structures.
Stricter building codes seem to be put in place in communities along the coast after rather than before a major hurricane. Lessons learned from storms like Hugo in 1989 and Andrew in 1992 are that most homes aren't disaster resistant. Given the growth of population near the coast, we will continue to see multi billion dollar losses and subsequent huge increases in insurance rates wherever a major hurricane strikes.

6. Extreme winds above the surface.
New instruments dropped from Hurricane Hunter aircraft can measure the wind accurately down to the surface of the earth and can be dropped into the eye wall of the storm. Data retrieved over the past two seasons has shown astonishingly stronger winds occurring some 500 to 1000 feet above the surface - as much as 30% or 1-2 categories higher! The implications for a direct hit on large downtown areas like Houston are ominous.

There are seldom easy solutions to these issues. But by maintaining an awareness of the problem and working to understand the complexity, we will be better prepared when the next major hurricane threatens our area.

BACK UP TO CONTENTS TABLE


El Niño and La Niña...Effects on Southeast Texas
By Gene Hafele

What's the difference between El Niño and La Niña?
El Niño and La Niña are extreme phases of a naturally occurring climate cycle referred to as El Niño/Southern Oscillation. Both terms refer to large-scale changes in sea-surface temperature across the eastern tropical Pacific. Usually, sea-surface readings off South America's west coast range from the 60s to 70s°F, while they exceed 80°F in the "warm pool" located in the central and western Pacific. This warm pool expands to cover the tropics during El Niño, but during La Niña, the easterly trade winds strengthen and cold upwelling along the equator and the West coast of South America intensifies. Sea-surface temperatures along the equator can fall as much as 7°F below normal.

Why do El Niño and La Niña occur?
El Niño and La Niña result from interaction between the surface of the ocean and the atmosphere in the tropical Pacific. Changes in the ocean impact the atmosphere and climate patterns around the globe. In turn, changes in the atmosphere impact the ocean temperatures and currents. The system oscillates between warm (El Niño) to neutral or cold (La Niña) conditions on average every 3-4 years.

What are the impacts of La Niña and El Nino in Southeast Texas?
Most of the impacts usually occur from the Fall through the Spring time. During an El Nino event (1997-98) with the jet stream further south, Southeast Texas will experience above normal rain and somewhat cooler temperatures. This was pretty much the case during the winter of 97-98. In a La Niña episode with the jet stream removed further north drier than normal conditions along with warmer conditions will prevail. During the current La Niña episode our average monthly temperatures have been above normal since it began late last summer. Precipitation during the winter months of 98-99 were generally below normal but many areas have received above normal rainfall during the late spring into the early summer.

How often does La Niña occur?
El Niño and La Niña occur on average every 3 to 5 years. However, in the historical record the interval between events has varied from 2 to 7 years. According to the National Centers for Environmental Prediction, this century's previous La Niñas began in 1903, 1906, 1909, 1916, 1924, 1928, 1938, 1950, 1954, 1964, 1970, 1973, 1975, 1988, and 1995. These events typically continued into the following spring. Since 1975, La Niñas have been only half as frequent as El Niños.

How is La Niña influencing the Atlantic and Pacific hurricane seasons?
Dr. William Gray at the Colorado State University has pioneered research efforts leading to the discovery of La Niña impacts on Atlantic hurricane activity, and to the first and, presently only, operational long-range forecasts of Atlantic basin hurricane activity. According to this research, the chances for the continental U.S. and the Caribbean Islands to experience hurricane activity increases substantially during La Niña.

Despite this increase in hurricane activity during La Niña episodes in the Atlantic Basin, the Texas Coast does not necessarily receive more storms in La Niña years. The hurricanes to make landfall along the Texas Coast were Chantal and Jerry in 1989 when we were transitioning from an El Niño in the early summer to a weak La Niña by the Fall of 1989. Hurricane Alicia...a category 3 hurricane that made landfall in 1983... occurred during a moderate El Niño condition.

What impacts do El Niño and La Niña have on tornadic activity across the country?
Since a strong jet stream is an important ingredient for severe weather, the position of the jet stream determines the regions more likely to experience tornadoes. Contrasting El Niño and La Niña winters, the jet stream over the United States is considerably different. During El Niño the jet stream is oriented from west to east over the northern Gulf of Mexico and northern Florida. Thus this region is most susceptible to severe weather. During La Niña the jet stream extends from the central Rockies east-northeastward to the eastern Great Lakes. Thus severe weather is likely to be further north and west during La Niña than El Niño.

During the winter of 97-98 we experienced prolonged periods of severe weather from November into early March as the jet stream was positioned along the northern portion of the Gulf of Mexico. The state of Florida experienced one of the worst tornado outbreaks in recent history during this time period. The spring of 1999 was a relatively mild severe weather season for southeast Texas as the positioning of the jet stream maintained a more northerly position.

Where can I find more information on La Niña?
The Internet is the greatest source of information on El Niño, La Niña and weather and climate data. NOAA has created one primary web site that allows you to link to many other resources: http://www.elnino.noaa.gov.

Specific information on La Nina predictions and other background is available at NOAA's Climate Prediction Center: http://www.cpc.ncep.noaa.gov.

Information on NOAA's latest research initiatives is available from the Climate Diagnostic Center: http://www.cdc.noaa.gov/ENSO/.

BACK UP TO CONTENTS TABLE



Heat Safety Rules

About 175 people die in this country every year due to excessive heat. When the Heat Index gets above 90 then it is time to take some precautions:

  • Slow down. Strenuous activities should be reduced, eliminated, or rescheduled to the coolest time of the day. Individuals at risk should stay in the coolest available place, not necessarily indoors.
  • Dress for summer. Lightweight, light-colored clothing reflects heat and sunlight, and helps your body maintain normal temperatures.
  • Put less fuel on your inner fires. Foods (like proteins) that increase metabolic heat production also increase water loss.>
  • Drink plenty of water or other non-alcohol fluids. Your body needs water to keep cool. Drink plenty of fluids even if you don't feel thirsty. Persons who have epilepsy or heart, kidney, or liver disease, are on fluid restrictive diets or have a problem with fluid retention should consult a physician before increasing their consumption of fluids.
  • Do not drink alcoholic beverages.
  • Do not take salt tablets unless specified by a physician. Persons on salt restrictive diets should consult a physician before increasing their salt intake.
  • Spend more time in air-conditioned places. Air conditioning in homes and other buildings markedly reduces danger from the heat. If you cannot afford an air conditioner, spending some time each day (during hot weather) in an air conditioned environment affords some protection.
  • Don't get too much sun. Sunburn makes the job of heat dissipation that much more difficult.

BACK UP TO CONTENTS TABLE



Tropical Funnels and Waterspouts
By Richard Hitchens

The summer months in southeast Texas are notorious for being hot and humid. Heat and humidity near the surface cause the atmosphere to become unstable, which leads to enhanced potential for parcels of air to rise and cool. Rising and cooling air, with sufficient moisture, can turn into clouds, showers and even thunderstorms.

On otherwise quiet weather days, the vertical motion associated with clouds and showers can become quite strong, especially around boundaries near the surface between differing air masses. The upper Texas coastline acts as an almost permanent airmass boundary during the summer months. During the morning, land areas heat up very rapidly. The Gulf coastal waters, by contrast, undergo only a very slow rise in temperature through the mid summer months, and change very little temperature-wise during the course of one day. During the morning, a front develops along the coastline and moves inland through the afternoon. Forecasters refer to this front as a "seabreeze front". It is not uncommon for showers and thunderstorms to develop along the seabreeze front.

Winds will shift slightly and increase in speed when the seabreeze front passes by. This is an indication of low level wind shear around the front. This, combined with the instability of the atmosphere during the summer, will cause the rising currents of air near the front to begin to rotate. In spots where the rising motion is especially vigorous, a funnel cloud can form. Luckily, these funnel clouds do not normally last very long and only rarely will touch down. Wind speeds are normally no higher than 40 to 70 mph.

Two tropical funnel touchdowns were reported in the area in early June. One touched down briefly on the east side of downtown Houston on the 8th and damaged a warehouse. On the 9th, a touchdown was reported in Surfside along County Road 257. No damage occurred.

Another weather phenomenon associated with a tropical environment is the waterspout. The waterspout is basically a tornado over the water. Showers will sometimes form over the Gulf waters due to high instability and can eventually grow into thunderstorms. While the showers are developing, intense updrafts can occur, feeding moisture and unstable air into the developing rain area. At the same time, downdrafts begin to occur in the area where rain is falling. The dividing line between the updraft and downdraft is referred to by forecasters as an "outflow boundary". This boundary can sometimes lead to the formation of brief waterspouts. Waterspouts can be very dangerous for mariners because they produce a sharp increase in wind speeds, sometimes higher than 50 knots. Waterspouts in the past have caused boats to capsize and have produced fatalities. Infrequently, a waterspout will move inland and produce damage. This occurred this past July 12th in Texas City. A waterspout moved inland briefly, and tore a roof from a section of an apartment building and produced minor damage to some adjacent properties. Luckily, there were no injuries.

When you are out on the water, you should keep an "eye to the sky" when you see cumulus clouds beginning to develop vertically. This is a favored area for waterspouts to eventually form. If you see a spout, move away from it quickly. Tropical waterspouts usually do not move faster than 20 mph, so moving rapidly away from them on the open water is your best way to stay safe. Waterspouts normally last between two and twenty minutes.

Tropical funnels and waterspouts produce lower wind speeds than tornadoes and severe thunderstorms. Tornadoes, in contrast to waterspouts and tropical funnels, form at the base of large rotating thunderstorms, known as mesocyclones, and can pack winds in excess of 200 mph. One disadvantage of tropical funnels and waterspouts is that they are very hard to detect on radar because they are small, short-lived, and rotation is confined to the very low levels of the atmosphere. A visual sighting is usually the only method the NWS has for issuing a warning or statement for a tropical funnel or waterspout.

Over the upper Texas coastal waters, the favored period for formation of tropical waterspouts is during the mid and late morning through early afternoon.

BACK UP TO CONTENTS TABLE



CO-OP CORNER
By Don Oettinger

We would like to express our sympathy to the family and friends of Ross Madole. Mr. Madole was the cooperative observer in Madisonville for over forty years. In 1985 he received the John Campanius Holm Award from the National Weather Service for "26 years of public service to his community and state for observing and recording temperature and rainfall data for Madisonville, Texas".

OBSERVING TIPS

When filling out the WS Form B-91 it is important to record the temperature and/or rainfall data on the correct date. This data should be recorded on the date that the readings are taken, not necessarily the date on which they occurred. For example, if you are taking a reading on the morning of the 2nd, the values that you read should be recorded on the line of the B-91 for the second day of the month. Even though the high temperature and possibly the rainfall actually happened on the 1st, it is still written on the 2nd. Most cooperative observers take their readings in the morning. The National Climatic Data Center is aware of the times the readings are taken and when they publish your data, the high temperature that is recorded on the 2nd day of the month is published as the high for the 1st. Please keep this in mind when filling out the B-91s. If the readings are entered on the wrong day the data will be skewed when received by NCDC and possibly not published.

If you have any questions, need supplies, or have equipment problems please call Tom or Don at (281.337.5074). If you don't have our 800 number we'll be glad to give it to you. You can also email us at tom.fountain@noaa.gov or don.oettinger@noaa.gov.

Thanks for your continued support of the Cooperative Observing Program.

BACK UP TO CONTENTS TABLE


Be Afraid...Be Very Afraid
Staff Spotlight
...Tom Fountain...

Name: Tom Fountain
Office: NWS Houston/Galveston (HGX), League City, TX
Position: Hydro-Meteorological Technician (HMT)
Favorite TV Show:"Dharma and Greg"

Personal Info
Hometown: Born in Rogers, AR, but raised in Texarkana, TX
Birthday: January 10, 1941
Other: Married (39 years!), 2 kids, 7 grandkids, 1 llama

NWS Background
1974 .... HMT, NWS Lubbock, TX
1978 .... HMT, NWS Galveston, TX
1984- .. HMT, NWSO Houston/Galveston, TX

Duties/Career Highlights/Other Tidbits

  • Primary duties are managing the Co-Operative Observer (Co-Op) Program and Public Service shifts which include the maintaining and updating local NOAA Weather Radio broadcasts, incoming public phone calls, assisting forecasters with daily forecasts and severe weather duties
  • Favorite actor of all time is John Wayne
  • One of the last of the remaining "original" crew that helped move the office from Alvin in 1990 to our current location
  • Served in both the Air Force and Navy (1960-1974) prior to the NWS
  • Participated in the GULFMEX study in 1989
  • Can do the macarena, the merengue, and really mean mambo
  • Helped set up the original COOP telephone rainfall system (ROSA) in 1987



What is your most memorable weather event?
Hurricane Alicia in 1983. I did not leave the office for 4 straight days including landfall. The storm also destroyed my beach house on the north side of the island.

Favorite food?
Mexican and BBQ (tied)

What are some of the biggest changes you have seen during your NWS career?
Definitely computers and satellites. In the old days, everything was done by hand (e.g. maps) and teletypes were very restricting. Now, with AWIPS, there is a thousand times more information available.

Any retirement plans?
Travel, including a trip to Bryce Canyon, UT

BACK UP TO CONTENTS TABLE



Severe Weather Update
By Brian Kyle

The New Year's Day tornado outbreak was covered in the last edition of Storm Signals. Since then, southeast Texas has seen a somewhat active late winter/spring severe weather season compared to the previous couple of years. Over 325 Severe Thunderstorm/Tornado/Flash Flood Warnings have been issued for the first 6 months of the year. To date, every single county (23 total) that this office warns for has reported some type of hail/wind/flood damage. Polk, San Jacinto and Trinity counties have been particularly active with a total of 43 combined reports of damage. Since all of the severe weather events cannot be covered in this short amount of space, highlights of the most significant storms are described below.

On January 22nd, a supercell thunderstorm moved directly over the Bryan/College Station area. Though no tornadoes were reported, very large hail fell across that region causing damage to windows, roofs, and cars. Widespread reports of golfball sized hail were common. Some stones as large as softballs fell on northern portions of the Texas A&M campus. At last report, damage totals exceeded $10 million.

Polk County suffered major flooding on March 13th and again on April 3rd. On the 3rd, a rainfall report called in from the Lake Livingston Dam indicated nearly 8.5 inches of rain fell in less than 4 hours! Needless to say, widespread flooding occurred and residents near Choates Creek in Livingston had to be evacuated from their homes. The region was declared a disaster area by Governor George W. Bush shortly thereafter. San Jacinto county also saw flooding that day with 6 to 9 inch rainfall totals.

A weak line of storms moving in from the Hill Country rapidly strengthened along the southern I-45 corridor on May 10th. Winds in the 55-75 mph range were common as the squall line moved across causing structural damage to homes and businesses and blowing down powerlines and trees. There were also some short lived tornadoes between Alvin and Pearland. The hardest hit was the Houston metropolitan area, though quite a bit of damage was also reported in Fort Bend, Montgomery, Brazoria, Galveston and Liberty Counties.

Hopefully, we'll have a quiet summer and keep the longest record of not being hit with a hurricane intact!

BACK UP TO CONTENTS TABLE



Houston Chapter of the American Meteorological Society
By Robert C. Van Hoven

The annual election of officers was held last May. The new officers (with their phone and e-mail addresses) are:



President
Cecilia Sinclair
(713) 625-1973
foxwxgal@hotmail.com
Vice-President
Lew Fincher
(281) 996-1064
hurracon@flash.net
Treasurer
Doris Rotzoll
(281) 483-1041
doris.rotzoll@jsc.nasa.gov
Secretary
Dorri A. Breher
(713) 529-3076
dbreher@wxresearch.com

Cecilia Sinclair works as a meteorologist for FOX TV 26. She was a previous president of the Local Chapter. Lew Fincher works for Dupont Chemical as a Hurricane Preparedness Specialist. Doris Rotzoll is a meteorologist at NASA's Space Meteorology Group. Dorri Breher works as a meteorologist for the Weather Research Center.

Of interest, Lew was honored at the 21st National Hurricane Conference in Orlando, Florida on April 1 and was presented the 1999 Outstanding Achievement Award. He was recognized for organizing a hurricane preparedness safety program for the Dupont Chemical Plant in La Porte, Texas. This concept was expanded to other plants along the Gulf, Atlantic, and Caribbean coasts. This was further expanded to other petrochemical companies to the extent that he is now recognized as the "Founding Influence" in petrochemical hurricane preparedness along the U.S. Atlantic and Gulf coasts.

The officer's planning meeting was held last June and meetings/speakers for the upcoming months are being lined up. The August meeting for all members will be on Thursday the 12th. It will be held at the Golden Corral at 12500 Gulf Freeway by Fuqua (713) 947-1162 . Time of dinner is 6 pm followed by the meeting. James R. Bailey of EQE International will talk about ways to mitigate wind damage to homes, businesses and industries. Lonny Farmer of Plylox will demonstrate a patented device called the Plylox clip which makes protecting windows and doors easier and faster.

BACK UP TO CONTENTS TABLE


EMWIN Houston
By Gene Hafele

The Emergency Managers Weather Information Network (EMWIN) datastream is broadcast in the Houston area on 150.435 MHz. With the proper equipment, you can receive and display the EMWIN broadcast which includes virtually all National Weather Service text and graphic products, such as forecasts, watches, warnings, and hourly conditions from weather forecast offices in Texas, Oklahoma, and Louisiana.

EMWIN Houston is a public service of the Harris County Appraisal District, Harris County Office of Emergency Management, the Texas National Guard, and the National Weather Service. The broadcast is supported by volunteer amateur radio operators who participate in RACES, the Radio Amateur Civil Emergency Service.

The EMWIN datastream is received from the GOES 8 and 10 satellites by satellite dishes on top of the Harris County Appraisal District building near US 290 and Loop 610. Data of interest to users in the Houston area is then sent via a leased line data circuit to a 200 watt transmitter on top of the Exxon Corporation building in downtown Houston.To utilize this signal, you will need an IBM compatible computer, a VHF radio or scanner capable of receiving the FM data transmission on 150.435 MHz, an EMWIN demodulator, and software. There are no recurring costs involved. Depending on your distance from the transmitter site, a vertically polarized outside antenna (scanner or 2-meter amateur radio type) may be required. Generally, the signal is useful within a 35 to 40 mile radius of downtown Houston.

This is the equipment you will need to properly utilize the EMWIN weather information: Computer: A minimum of a Pentium 100 computer with at least 32 MB of RAM running Windows 95/98/NT. Users must reserve 30 MB of hard disk space for the program and data files. The computer must have one free serial COM port and your video card must support 256 colors. Radio Receiver: Any standard VHF public service radio scanner with either a headphone or speaker output jack and a volume control, that is able to receive an FM signal at 150.435 MHz. Software: WeatherNode version 4.0 or RealEMWIN software and an EMWIN demodulator. Software and demodulators are available from commercial sources for less than $100 total.

In addition to the VHF broadcast, EMWIN Houston's data is transmitted over the Internet by "push" broadcast. To receive the Internet datastream, the end user must install WeatherNode 4.0 software and the associated ByteBlaster client. The ByteBlaster should then be set for connection to 207.80.106.33. A demonstration version of WeatherNode 4.0 and ByteBlaster can be downloaded from the Wx4U website shown below. We recommend that users within range of the VHF broadcast receive the signal directly "off-the-air" since the broadcast datastream is not affected by Internet loading during periods of heavy use.

Commercial Vendors
The NWS uses radio, satellite and Internet broadcasts for disseminating the EMWIN data stream. RECEPTION and REPEATING of all broadcasts requires specialized equipment or software, available commercially (some for free). The following vendors supply software and/or general off-the-shelf hardware or specialized equipment useful for receiving and using EMWIN data.



Wx4u, Inc.

WeatherNode
3392B Ft. Meade Road
Laurel, MD 20724
(301) 725-4009
http://www.wx4u.com/
Zephyrus Electronics, Ltd

171 S. 122 E. Avenue
Tulsa, OK 74128-2405
Phone: (918) 437-3333
Fax: (918)438-7322
http://www.big-z.com/
Weather Graphics Technologies,Inc.

P.O. Box 450211
Garland, TX 75045
(888) 388-0070
(405) 573-0700
Fax: (972) 495-6848
http://www.weathergraphics.com/
RealEMWIN

Skywatch Weather Services
http://www.skywatch.org/
SkyWalker Data Systems, Inc.

7303 West 35th St.
Tulsa, OK 74107
(918) 445-1488
http://www.skywin.com/
DuMond R/C Service Company

2626 Valley View, Suite #4
Farmers Branch, TX 75234 (near Dallas)
(972) 241-8492
http://www.weathernode.com/dumond/index.htm
Tigertronics
400 Daily Lane
P.O. Box 5210
Grants Pass, Oregon 97527
Phone: (541) 474-6700
Fax: (541) 474-6703
http://www.tigertronics.com

Note: A listing here does not imply any particular endorsement by the Harris County Appraisal District, Harris County Office of Emergency Management, or NWS as to function or suitability for your purpose or environment.

To other potential EMWIN vendors: If you would like to be listed here, please contact us and provide the pertinent details. Send details by e-mail to emwin-houston@emwin.hcad.org.

For Additional EMWIN Information: http://iwin.nws.noaa.gov/emwin/index.htm

BACK UP TO CONTENTS TABLE


Storm Signals Survey

Dear Storm Signals Reader:

The Houston/Galveston NWS is looking for ways to cut down on the costs of publishing and mailing the Storm Signals Newsletter. We would like to convert it to an electronic medium for many of our readers. This would make it easier for you to forward all or a portion of the Newsletter to some of your colleagues. Please answer the following questionnaire and return to the Houston/Galveston NWS as soon as possible. We currently post the newsletter on our homepage but are also thinking of sending it via email in the future.

Click here for the survey. Please note, if you print now, you could print the ENTIRE document!

BACK UP TO CONTENTS TABLE
